Communications Settings for the Target PLC

♦ If the PLC Backup Tool is started from the CX-Programmer Tools Menu, the communications of the
CX-Programmer will be inherited.
♦ If the PLC Backup Tool is started from the Windows Start Menu, click the Communication Settings Button
and specify the PLC to connect to.
Direct Connection to PLC
A direction connection can be made for either a serial or network connection.
PLC Backup Tool
Connection to PLC via Gateway PLC
PLC Backup Tool
Connected PLC
Network
PLC Backup Tool
Gateway PLC
Network
Connected PLC
Connected PLC
