PART 1: CX-Programmer
CHAPTER 3 – Project Reference
SFC
It is possible to set the display settings for the SFC diagram editor.
For details, refer to the CX-Programmer Operation Manual SFC (Cat. No. W469).
Magnification
The magnification level (i.e. zoom) of the Diagram view can be adjusted to display more or less information as
required. If the diagram is zoomed out then the font becomes smaller and more diagram elements can be seen.
Use the following procedure to set magnification levels.
1, 2, 3...

Finding and Replacing

CX-Programmer provides facilities for finding references to particular text, and replacing text with other text.
There are also powerful replacement options, such as moving a range of addresses to another starting point. The
Search and Replace functionality consists of two dialogs, depending on which operation is being executed. The
Find dialog is opened from the EDIT | Find menu option or the key combination Ctrl+F. The Replace dialog is
opened from the EDIT | Replace menu option or by pressing Ctrl+H.
It is possible to find and replace text from various places: the project workspace, diagram workspace (ladder or
mnemonic views), a symbol table, and an I/O Comment view.
When using the Find and Replace feature from the project workspace, the operation searches the chosen object,
including any objects within it. For example, when finding text from a program within the project workspace,
the local symbol table for that program is also searched. When beginning a search from the project object itself,
everything within the project is searched.
It is also possible to limit the search to a single program window, symbol table, or I/O Comment view by
beginning the search when the relevant ladder, symbol table, or I/O comment window is active.
When Change All is selected from the Edit menu option, the Change All dialog to replace Addresses within
the PLC will be opened. Enter the Find what and Replace with text as described in Using Find and Replace in
this chapter, the replacement of the text will be applied throughout the entire PLC.
CX-Programmer _Page 44
1. Open the Diagram Workspace.
2. Select the Zoom In button or the Zoom Out button from the toolbar to change the
Diagram Workspace.
3. Select the Zoom to Fit button to change the size of the program width to the length of
the Diagram view.
