PART 2: CX-Server PLC Tools
CHAPTER 10 – Data Links
Select for manual
setup.
For automatic
setup, select CIO
only, DM only, or
CIO and DM.
For automatic setup,
select from among the
following areas and
words.
• CIO 04CH, DM 08CH
• CIO 08CH, DM 16CH
• CIO 16CH, DM 32CH
• CIO 32CH, DM 64CH
5 Select the memory area for automatic setup (CIO Area only, DM Area only, or CIO and DM Areas), and select
the area and word settings from the following list.
Reference
Word Allocations for SYSMAC LINK Automatic Setup (Example: CS/CJ Series, CVM1/CV Series)
CIO Area (words)
CIO 1000 to CIO 1003
CIO 1004 to CIO 1007
CIO 1008 to CIO 1011
CIO 1012 to CIO 1015
CIO 1016 to CIO 1019
CIO 1020 to CIO 1023
CIO 1024 to CIO 1027
CIO 1028 to CIO 1031
CIO 1032 to CIO 1035
CIO 1036 to CIO 1039
CIO 1040 to CIO 1043
CIO 1044 to CIO 1047
CIO 1048 to CIO 1051
CIO 1052 to CIO 1055
CIO 1056 to CIO 1059
CIO 1060 to CIO 1063
CX-Server PLC Tools_Page 130
CIO: 4
DM Area (words)
words
DM: 8
words
D00000 to D00007 #1
D00008 to D00015 #2
D00016 to D00023 #3
D00024 to D00031 #4
D00032 to D00039 #5
D00040 to D00047 #6
D00048 to D00055 #7
D00056 to D00063 #8
D00064 to D00071 #9
D00072 to D00079 #10
D00080 to D00087 #11
D00088 to D00095 #12
D00096 to D00103 #13
D00104 to D00111 #14
D00112 to D00119 #15
D00120 to D00127 #16
Reads settings data
from the PLC.
Transfers settings
data to the PLC.
Area and word settings
CIO: 16
CIO: 8 words
words
DM: 16
DM: 32
words
words
#1
31
#2
#3
#2
#4
#5
#3
#6
#7
#4
#8
OMRON
CIO: 32
words
DM: 64
words
