Memory Area Conversion Table
The memory addresses used in the operands are automatically converted.
Memory area
IR Area/SR Area
(CIO Area)
Temporary Relay
Area
HR Area (Holding
Area)
LR Area (Link
Area)
Timer Area
Counter Area
Data Memory
Area
Data Memory
Area (indirect
addressing)
Hexadecimal
constant
BCD constant
Decimal constant
CHAPTER 6 – Converting a C500/C120/C**P Program to CS/CJ/CP/CVM1 Format
Before conversion
C500/C120 C**P
00 to 63 00 to 04 0 to 63
TR0 to TR7 TR0 to TR7
HR00 to HR31 HR0 to 9 H0 to H31
LR00 to LR31 (None) 1000 to 1031
TIM0 to
TIM0 to TIM127 T0 to T127
TIM47
CNT0 to
CNT0 to CNT127 C0 to C127
CNT47
DM0 to
DM000 to DM511 D0 to D511
DM63
*DM000 to
*D0 to *D511
*DM511
#0000 to #FFFF #0 to #FFFF
#0000 to #9999 #0 to #9999
#0000 to #9999 &0 to &65535
After conversion
CS/CJ
CV Series
Series
00 to 31: I/O Area
32 to 57: IR Area
58: PC Link Area (IR Area)
59: Remote I/O Area (IR Area)
58.00 to 63.07: AR Area
---
1200 to
---
1231
---
---
---
---
---
See the Instruction Conversion
Table.
