Settings on [Trace Object] Tab
Set the object of Time Chart Monitor. The operation procedure is as same as the one on the previous topic:"
Parameter Settings of Data Trace for CS/CJ/CP". Refer to settings on [Trace Object] tab on the previous topic.
Execute Time Chart Monitor with Data Trace Window for CS/CJ/CP
Execution operation of Time Chart Monitor will be discussed. Parameter settings are necessary prior to executing
Time Chart Monitor.
Operation of Time Chart Monitor
1 Select [Operation]| [Execute] on Data Trace Window (or click on
appear in Data Trace window.
Select [Operation]| [Trigger] (or click on
2 Sampling starts when trigger conditions are completed.
Select [Operation]| [Stop] to stop Time Chart Monitor (click on
3 In case that [Sampling] tab| [Stop When Buffer is Full] is checked in [Time Chart Monitor Configuration]
dialog box, sampling automatically stops when buffer is full and Time Chart Monitor screen stops.
Refer to the previous topic: "Parameter Settings of Time Chart Monitor" for [Time Chart Monitor
Configuration] dialog box.
Item
Select [Trace].
Select the sampling conditions of Time Chart Monitor.
[Fixed Interval]
Sampling with fixed intervals. Set sampling cycle in milliseconds.
I/O data per sampling cycle is sampled.
[Buffer Size]
Operate sampling with the specified sample number. The old
sampling data will be destroyed automatically.
[Stop When Buffer is Full]
Check on the box. Sampling will stop when the set buffer size is
reached.
[Left Operand] Input Symbol for trigger object or the address. Select data type
from Combobox.
[Browse] Search trigger objects from Symbol Table.
[Formula] Select the conditions of trigger completion.
[Left Operand] is a bit (data type is BOOL):
↑ Falling Edge
↓ Rising Edge
[Left Operand] is other than the above:
= Equal
[Right Input the value of trigger. Input is enabled when [Left Operand] is
Operand] except for a bit (data type is except for BOOL).
Input delay value in sample number. Input in slider is possible.
Check on the box to start Time Chart Monitor automatically after
transferring the execution conditions of Time Chart Monitor to
PLC.
) and trigger completion can be done.
