PART 2: CX-Server PLC Tools
CHAPTER 6 – PLC Error Component
only performed when the maximum number of records in the Error Log has been reached. Again this is PLC
dependent.
1, 2, 3...

Displaying the Error Log

The PLC Error component can be set so that it is only activated when an error in the PLC actually occurs
(providing it is already open); for example, if the PLC Error component has been minimised it automatically
returns to full size as the top window when an error is generated in the PLC.
1, 2, 3...
CX-Server PLC Tools_Page 74
1. Select the Settings option from the Options menu
2. Select the Error Log tab.
3. Check the Error Log Overwrite Mode setting to allow the PLC to overwrite Error Log
entries.
4. Select the Apply pushbutton to activate the settings. Select the OK pushbutton to apply the
settings and close the dialog. Select the Cancel pushbutton to abort the operation.
1. Select the Settings option from the Options menu.
2. Select the General tab.
3. Check the Activate only when Error detected setting.
