6. Click the OK Button. The following Comparison Results Dialog Box will be displayed.
Configuration: Indicates whether the
configurations match
between the backup
file and the PLC.
Setting: Indicates whether the
settings match
between the backup
file and the PLC.
7. The following operations can be carried out with the comparison results.
♦
Display details of the comparison results.
♦
Save comparison results in a file.
♦
Transfer backup file data to PLC.
The configuration in the The following is displayed for the
backup file on the computer Unit in the connected PLC (or
is displayed here: rack No., other backup file: unit version
and unit No.
slot No., model No., unit
version, and unit No.
PART 2: CX-Server PLC Tools
CHAPTER 12 – PLC Backup Tool
Source backup
file and PLC
model on the
computer.
Destination PLC
or backup file,
and PLC model.
