Standard Specifications
The standard specifications of the Analog Input Unit and Analog Power Supply Units conform to those of the
CQM1H/CQM1 PC.
Performance Specifications
CQM1-AD041 Analog Input Unit
Item
Input signal range
External input impedance
Resolution
Accuracy
Conversion speed
Maximum input signal
Insulation method
Current consumption
Weight
Dimensions
Note 1. Conversion data is refreshed every 10 ms (2.5 ms x 4).
2. Analog input terminals are not insulated from one another.
Appendix A
Specifications
Voltage input –10 to 10 V
0 to 10 V
1 to 5 V
Current input 4 to 20 mA
Voltage input 1 M max.
Current input 250
1/4000
0.5% (25 C)
1.0% (0 to 55 C)
2.5 ms/point (see note 1)
Voltage input 15 V max.
Current input 30 mA max.
Input terminals and PC signals are insulated with photocoupler (see note 2)
80 mA at 5 VDC excluding the current supplied from the Analog Power Supply Unit.
210 g
32 x 110 x 107 (W x H x D) mm
Specification
103
