Nomenclature
2-1
Nomenclature
Front View
Left Side View
Indicator
116
I1+
I1
V1+
V1
I2+
I2
V2+
V2
DA021
Terminal screws: M3
The green indicator of the Unit will
be lit if the Unit starts normally.
Indicator
Output terminal 1
Output terminal 2
Power supply cable
(Connect to Analog Power Supply Unit)
Indicator
JT1 setting pin
JT2 setting pin
Power supply cable
Section 2-1
