Specifications and General Information

2-1

Specifications and General Information

2-1-1 Specifications

General Specifications
Performance Specifications
8
All general specifications of the 3G2A5-AD001 through 3G2A5-AD005 Analog
Input Units conform to those of the C Series, except the following.
• Insulation between the External Terminals and the Frame:
5MΩ min. at 250 VDC
• Breakdown Voltage between the External Terminals and the Frame:
500 VAC, 50-60 Hz for 1 minute
Item
Number of analog inputs
Input signal range p g g
Max. input signal p g
External input impedance p p
Resolution
PC signal (see note 1)
Linearity error
Accuracy
Accuracy temperature coefficient ±100 PPM/°C (full scale)
Conversion time
Conversion cycle
Max. PC write delay
(see note 2)
Conversion method
Words allocated
External connections
Power consumption
External dimensions
Weight
Note 1. A sign bit + 11 data bits binary data for Units with –10 to 10 V and –5 to 5 V
range (3G2A5-AD004 and 3G2A5-AD005).
2. The PC write delay is the time required for a change in the input signal to be
converted and transferred to the PC bus.
Specification
2
Voltage input g p
AD001 1 to 5 V
AD002 0 to 10 V
AD003 0 to 5 V
AD004 –10 to 10 V
AD005 –5 to 5 V
Current input AD001 4 to 20 mA
±15 V max.
Voltage input
±60 mA max.
Current input
Voltage input 1 MΩ min.
250 Ω
Current input
1/4095 (full scale)
12-bit binary
±0.1% max.
±0.2% max. (full scale at 25°C)
2.5 ms max./point
5 ms max.
1 s max.
Sequential comparison
2 input words
17-pin terminal block (not removable)
500 mA max. at 5 VDC
34.5 x 250 x 113 mm (W x H x D)
600 g max.
Section 2-1
