Application

Current Detectors
(E54-CT1/CT3)
Heater
Output Interface
Output Characteristics
Built-in Short-circuit
Protection Circuit
Output Circuits
(
TC
2-6 Application
254
Control output
CT
Maximum switching capability
Leakage current
Residual voltage
External supply voltage
When the short-circuit protection circuit operates, turn OFF the output or the
output power supply, or release the short circuit.
(
01/TC 03
• The +DC terminals for NPN outputs are internally connected.
• The 0V terminals for NPN outputs are internally connected.
• Heater burnout alarm outputs (HB1 and HB2) are latched outputs, i.e.,
they will not reset by themselves.
The Unit will be in Auto Mode in STOP status when the power supply is turned
ON. An operation control command must be executed to start actual opera-
tion. Refer to 2-6-2 Using Operation Control Commands for details on the
commands.
AC power
100 mA, 24 VDC
0.1 mA max.
0.8 V max.
30 mA min., 24 VDC
ing load current)
( (
TC 02/TC 04
Section 2-6
Connect to CT input
terminals on the
Temperature Control
Unit (no polarity).
Heater wire
Current Detector
(E54-CT1/CT3)
+10%
/
–15%
+10%
/ (exclud-
–15%
