Switch Settings
Mode Selector
144
The following is an example of a sensor output operation chart.
Setting distance
Control output (OFF-
delay activated)
Control output
(OFF-delay deactivated)
Operation indicator
(orange)
Stability operation
indicator (green)
Note Set the switches on the side panel before mounting the Module to the Sensor
Unit.
Setting
RUN
SET
Note 1. Refer to 3-4-1 E3X-MA11 Optical Fiber Photoelectric Module for the fiber
lock lever of the E3X-MA11.
2. Refer to SECTION 4 Sensor Module Operation for details on the operation
of the mode selector and teaching button.
Sensing distance
Approx. 107%
100%
Approx. 93%
ON
OFF
ON
OFF
ON
OFF
ON
OFF
Normal operation
Sensitivity adjustment (teaching)
Section 2-2
10 ms
h
Function
