10. SPECIFICATIONS
10-2 Torque characteristics
CAUTION
(1) HC-MF series
(HC–MF053)
0.6
Short-duration operation region
0.4
0.2
Continuous operation region
0
1000 2000 3000 4000 4500
Speed [r/min]
(2) HA-FF series
(HA–FF053)
0.6
Short-duration
operation region
0.4
0.2
Continuous operation region
0
1000 2000 3000 4000
Speed [r/min]
(HA–FF23)
2.0
Short-duration
1.5
operation region
1.0
(Note)
0.5
Continuous operation region
0
1000 2000 3000 4000
Speed [r/min]
Note: The broken line indicates the torque characteristic of the servo motor used with the single-phase 100V
power supply series servo amplifier.
If load is opplied at stop (during servo lock), 70% of the rated torque must
not be exceeded.
(HC–MF13)
1.0
(Note)
0.75
Short-duration operation region
0.5
0.25
Continuous operation region
0
1000 2000 3000 4000 4500
Speed [r/min]
(HA–FF13)
1.0
Short-duration
operation region
0.75
0.5
0.25
Continuous operation region
0
1000 2000 3000 4000
Speed [r/min]
(HA–FF33)
3
Short-duration
operation region
2
(Note)
1
Continuous operation region
0
1000 2000 3000 4000
Speed [r/min]
(HC–MF23)
2.0
Short-duration
operation region
1.5
1.0
(Note)
0.5
Continuous operation region
0
1000 2000 3000 4000 4500
Speed [r/min]
(HC–MF73)
8.0
Short-duration
operation region
6.0
4.0
2.0
Continuous operation region
0
1000 2000 3000 4000 4500
Speed [r/min]
(HA–FF43)
4.0
Short-duration
3.0
operation region
2.0
(Note)
1.0
Continuous operation region
0
1000 2000 3000 4000
Speed [r/min]
10– 6
(HC–MF43)
4.0
Short-duration
operation region
3.0
2.0
(Note)
1.0
Continuous operation region
0
1000 2000 3000 4000 4500
Speed [r/min]
Note: The broken line indicates
the torque characteristic
of the servo motor used
with the single-phase
100V power supply series
servo amplifier.
(HA–FF63)
6.0
Short-duration
operation region
4.0
2.0
Continuous operation region
0
1000 2000 3000 4000
Speed [r/min]
