In this field...

Incoming Traffic:

Select this option to limit the rate of incoming traffic belonging to this

Limit rate to

class. Then type the maximum rate (in kilobits/second) in the field

DiffServ Code

Select this option to mark packets belonging to this class with a DiffServ

Code Point (DSCP), which is an integer between 0 and 63. Then type the

DSCP in the field provided.

The marked packets will be given priority on the public network according

to their DSCP.

To use this option, your ISP or private WAN must support DiffServ. You

can obtain the correct DSCP value from your ISP or private WAN

administrator.

Viewing and Deleting Classes

You cannot delete a class that is currently used by a rule. You can determine whether a

class is in use or not, by viewing the Rules page.

To view or delete an existing QoS class

Click Network in the main menu, and click the Traffic Shaper tab.

The Quality of Service Classes page appears with a list of all defined QoS classes.

To delete a QoS class, do the following:

In the desired class's row, click the Erase

A confirmation message appears.

Chapter 9: Using Traffic Shaper
