Check Point UTM-1 Edge User Manual page 229

To assign a port to...
VLAN or
VLAN Trunk
A WAN Internet connection
DMZ
Console
A VLAN network, dynamically
assigned by a RADIUS server
A printer
An RS232 Modem
A USB-based modem
To modify a port assignment
Click Network in the main menu, and click the Ports tab.
1.
The Ports page appears.
Next to the desired port, click Edit.
2.
Chapter 6: Managing Your Network
See...
Configuring VLANs on page 179
The procedure below.
Note: When you configure an Ethernet-based Internet
connection on a port, the port is automatically assigned to
Internet use. For information on configuring an Internet
connection, see Using Internet Setup on page 113.
Configuring a DMZ Network
Using a Console on page 589
Configuring Port-Based Security on page 348
Setting Up Network Printers on page 630
Setting Up an RS232 Modem on page 146
Setting Up a USB Modem on page 149
Managing Ports
215
