Using the Serial Console
You can connect a console to the UTM-1 appliance, and use the console to control the
appliance via the command line.
Note: Your terminal emulation software and your UTM-1 appliance's Serial port must
be configured for the same speed.
By default, the appliance's Serial port's speed is 57600 bps. For information on
changing the Serial port's speed, refer to the Embedded NGX CLI Reference
Guide.
To control the appliance via a console
1. Connect the serial console to your UTM-1 appliance's Serial port, using an
RS-232 Null modem cable.
For information on locating the Serial port, see Rear Panel on page 16.
Click Network in the main menu, and click the Ports tab.
2.
