LED
State
On (Green)
On (Red)
Flashing (Orange)
LINK/ACT Off, 100 Off
LAN 1-4/
WAN/
DMZ/WAN2
LINK/ACT On, 100 Off
LINK/ACT On, 100 On
LNK/ACT Flashing
VPN
Off
Flashing (Green)
On (Green)
Serial
Off
Flashing (Green)
USB
Off
Flashing (Green)
WLAN
Off
Flashing (Green)
Chapter 1: Introduction
The UTM-1 Edge X Series and UTM-1 Edge W Series
Explanation
Normal operation
Error
Software update in progress
Link is down
10 Mbps link established for the
corresponding port
100 Mbps link established for the
corresponding port
Data is being transmitted/received
No VPN activity
VPN activity
VPN tunnels established, no activity
No Serial port activity
Serial port activity
No USB port activity
USB port activity
No WLAN activity
WLAN activity
33
