UTM-1 Edge X and UTM-1 Edge W Installation
8.
Connect the UTM-1 appliance's end of the harness to the UTM-1 appliance, by
doing the following:
a.
Connect the 24V DC connector plug to the 24V power jack at the front of
the appliance.
b.
Turn on the 24V DC industrial power supply.
9.
Check that the appliance is operating correctly.
Installing UTM-1 Edge X ADSL and Edge W ADSL
To install the UTM-1 appliance
1.
Verify that you have the correct cable type.
For information, see Network Requirements on page 30.
2.
Connect the LAN cable:
Connect one end of the Ethernet cable to one of the appliance's LAN
a.
ports.
b.
Connect the other end to PCs, hubs, or other network devices.
3.
Connect the ADSL cable:
Connect one end of the telephone cable to the appliance's DSL port.
a.
b.
Connect the other end of the cable to the ADSL line or micro-filter.
In most cases, a micro-filter is required for each phone jack on your line. The
micro-filter prevents the standard phone lines from interfering with your ADSL
service. Check with your service provider whether a micro-filter is required at
your location.
4.
To use the appliance with a non-ADSL connection, or with an existing ADSL
modem, connect an Ethernet cable:
Connect one end of the Ethernet cable to the appliance's DMZ/WAN2 port.
a.
b.
Connect the other end of the cable to an external cable modem, DSL
modem, or office network.
72
Check Point UTM-1 Edge User Guide
