Using Port-Based Security
Configuring Port-Based Security
To configure 802.1x port-based security for a port
1. Configure RADIUS authentication on the appliance.
For instructions, see Using RADIUS Authentication on page 553.
2. Configure the clients for 802.1x authentication.
For information, refer to your RADIUS server documentation.
3. To configure dynamic VLAN assignment, do the following:
a. Add port-based VLAN networks as needed.
See Adding and Editing Port-Based VLANs on page 183.
b. Configure RADIUS option 81 [Tunnel-Private-Group-ID] on the
RADIUS server.
For information, refer to your RADIUS server documentation.
4. To configure a Quarantine network other than the LAN or DMZ, add a port-
based VLAN network.
See Adding and Editing Port-Based VLANs on page 183.
Click Network in the main menu, and click the Ports tab.
5.
