The UTM-1 Edge X Series and UTM-1 Edge W Series
Getting to Know Your UTM-1 Edge W ADSL Appliance
Package Contents
The UTM-1 Edge W ADSL package includes the following:
•
UTM-1 Edge W ADSL Internet Security Appliance
•
Power supply
•
CAT5 Straight-through Ethernet cable
•
Getting Started Guide
•
Documentation CDROM
•
Wall mounting kit
•
RS232 serial adaptor (RJ45 to DB9)
•
Two antennas
•
USB extension cable
•
RJ11 telephone cable
Network Requirements
•
10BaseT or 100BaseT Network Interface Card installed on each computer
•
CAT 5 STP (Category 5 Shielded Twisted Pair) Straight Through Ethernet cable
for each attached device
•
An ADSL line suitable for your appliance model:
•
For Annex A ADSL models, an ADSL over POTS line (regular telephone
line)
•
For Annex B ADSL models, an ADSL over ISDN line (digital line)
•
A splitter with a micro-filter, installed on all the jacks connected to the same
phone line
