Check Point UTM-1 Edge User Manual page 358

Using Rules
In this field... Do this...
Destination Select the destination of the connections you want to allow/block.
To specify an IP address, select Specified IP and type the desired IP address
in the text box.
To specify an IP address range, select Specified Range and type the desired
IP address range in the fields provided.
To specify the UTM-1 IP address, select This Gateway.
To specify any destination except the UTM-1 Portal and network printers,
select ANY.
If the current time Select this option to specify that the rule should be applied only during
is certain hours of the day.
You must then use the fields and drop-down lists provided, to specify the
desired time range.
Forward the Select the destination to which matching connections should be forwarded.
connection to
To specify an IP address, select Specified IP and type the desired IP address
in the text box.
This field only appears when defining an Allow and Forward rule.
Quality of Select the QoS class to which you want to assign the specified connections.
Service class
If Traffic Shaper is enabled, Traffic Shaper will handle these connections as
specified in the bandwidth policy for the selected QoS class. If Traffic Shaper
is not enabled, this setting is ignored. For information on Traffic Shaper and
QoS classes, see Using Traffic Shaper.
This drop-down list only appears when defining an Allow rule or an Allow and
Forward rule.
344 Check Point UTM-1 Edge User Guide
