Table 39: Ports Fields
This field...
Assign To
Status
Chapter 6: Managing Your Network
Displays...
The port's current assignment.
For example, if the DMZ/WAN2 port is currently used for the DMZ, the
field displays "DMZ".
The port's current status. This can be any of the following:
•
The detected link speed and duplex (Full Duplex or Half
Duplex)
•
No Link. The appliance does not detect anything connected
to the port.
•
Disabled. The port is disabled. For example, the DMZ/WAN2
port's status will be "Disabled" if the port is assigned to
"None", or if it assigned to "DMZ" and the DMZ is disabled.
•
No Sync. The ADSL modem failed to synchronize with the
ADSL service provider. Check that a micro-filter is properly
connected, and check that your DSL Standard setting is
compatible with your service provider. You can view this
setting in the Network > Internet Setup page.
This status is relevant for the ADSL port only.
•
Connected (number). USB devices (printers or modem) are
connected to the USB ports. The number of connected
devices appears in parentheses.
This status is relevant for the USB ports only.
•
Not Connected. No USB devices are connected to the USB
ports.
This status is relevant for the USB ports only.
