Configuring an Ethernet-Based Connection on ADSL
Models
Note: In ADSL models, an Ethernet-based connection is made on the DMZ/WAN2
port.
To configure an Ethernet-based connection
Click Network in the main menu, and click the Internet tab.
1.
The Internet page appears.
Click Internet Wizard.
2.
The Internet Wizard opens with the Welcome page displayed.
Click Next.
3.
The Internet Connection Port dialog box appears.
Click Use the WAN2 port to connect to another network or router.
4.
Click Next.
5.
