Electrical Specifications

The following table lists the maximum ratings for the power supplies used in the
server. The listed power numbers are not the actual rated power consumption of the
system.
Use the online power calculator to determine the power consumption of a server
with your configuration. To located the appropriate power calculator, go to the
following web site and navigate to the SPARC T3-2 server page:
http://www.oracle.com/goto/powercalculators/
Note – Plan to connect each power supply to a separate circuit if possible. This
redundancy enables the server to remain operational if one of the circuits fails.
Consult your local electrical codes for any additional requirements.
Parameter
Input
Nominal frequencies
Nominal AC operating voltage range
Maximum current AC RMS per power cord
Volt-Ampere rating
Power factor
Power dissipation
Max power consumption of power supply
Max heat output
Inrush current (peak)
Leakage current
Output
3.3 VDC STBY
+12 VDC
6 SPARC T3-2 Server Installation Guide • March 2012
Value
50 / 60 Hz
200 to 240 VAC
12 A @ 200 VAC
2218 VA @ 240 VAC
0.98 P.F. @ 240 VAC, full load
2175 W
7417 BTU/hr
25 A
1.6 mA
10 A
165 A
