6. Insert the left CMA slide rail connector into the left slide rail assembly until the
connector locks into place with an audible click.
Inserting the CMA Slide Rail Connector Into the Back of the Left Slide Rail
FIGURE:
Figure Legend
1
CMA slide rail connector
2
Left slide rail
7. Install and route cables to your server, as required.
Note – Instructions for installing the server cables are provided in
Server Cables" on page
8. If required, attach the cable hooks and loop straps to the CMA, and press the
hooks and straps into place to secure the cables.
35.
"Connecting the
Installing the Server
31
