Oracle Sun SPARC T3-2 Installation Manual page 63

Note – When you power on the server for the first time and you do not have a
terminal or terminal emulator (PC or workstation) connected to the SP SER MGT
port, you will not see system messages.
3. (Optional) Connect an Ethernet cable between the server's NET MGT port and
the network to which future connections to the SP and host will be made.
Note – After the initial configuration of the system using the SP SER MGT port,
communication with the SP and host is usually performed through this Ethernet
interface.
4. Connect an Ethernet cable between one of the server's Gigabit Ethernet ports
and the network to which the server will communicate.
For instructions, see
5. Plug the power cords into the power supplies and into separate power sources.
To provide redundancy, plug both power supplies into separate power sources.
The system can operate with only one power connection, but there will be no
redundancy.
The service processor runs on 3.3V standby voltage. As soon as AC power is
connected to the system, the front panel SP OK/Fault LED flashes as the service
processor powers on, runs diagnostics, and initializes the ILOM firmware.
Front Panel Main Power and SP LEDs
FIGURE:
Figure Legend
1 Main Power/OK LED
2 SP OK/Fault LED
After the ILOM firmware initializes, the SP OK/Fault LED remains lit, the main
power OK/Fault LED slowly flashes, and the SP login prompt displays on the
terminal device. The host is not initialized or powered on yet.
"Connect the Ethernet Network Cables" on page
Powering On the Server for the First Time
41.
53
