Disassembling the Slide Rail Before Installation
FIGURE:
Figure Legend
1
Slide rail lock
2
Mounting bracket release button
3. Press and hold the slide rail lock toward the direction of the arrow while you
pull the mounting bracket out of the slide rail assembly until it reaches the
stop.
4. Push the mounting bracket release button toward the front of the mounting
bracket, and simultaneously withdraw the mounting bracket from the slide rail
assembly.
5. Repeat for the remaining slide rail assembly.
Related Information
"Install Mounting Brackets" on page 22
■
"Attach Slide Rail Assemblies" on page 23
■
"Install Server Into the Slide Rail Assemblies" on page 26
■
Installing the Server
21
