▼ Verify Operation of Slide Rails and
CMA
Use the following procedure to ensure that the slide rails and CMA are operating
correctly.
Note – Two people are recommended for this procedure: one to move the server in
and out of the rack, and one to observe the cables and CMA.
1. Slowly pull the server out of the rack until the slide rails reach their stops.
2. Inspect the attached cables for any binding or kinks.
3. Verify that the CMA extends fully from the slide rails.
4. Push the server back into the rack, as follows:
When the server is fully extended, you must release two sets of slide rail stops to
return the server to the rack:
a. The first set of stops are levers, located on the inside of each slide rail, just
behind the back panel of the server. Push in both green levers
simultaneously and slide the server toward the rack.
The server will slide in approximately 18 inches (46 cm) and stop.
Verify that the cables and the CMA retract without binding before you
continue.
b. The second set of stops are the slide rail release buttons, located near the
front of each mounting bracket. Simultaneously push both of the green slide
rail release buttons, and push the server completely into the rack until both
slide rail locks engage.
5. Adjust the cable straps and CMA, as required.
Related Information
"Install the CMA" on page 28
■
"Secure Cables to CMA" on page 47
■
