Component
PCI Express 2.0 I/O slots
Network module slot
Ethernet ports
Service processor
Power supplies
Cooling fans
Management software
Related Information
SPARC T3-2 Server Service Manual
■
Oracle ILOM documentation
■
"Front Panel Components" on page 12
■
"Back Panel Components" on page 13
■
4 SPARC T3-2 Server Installation Guide • March 2012
Description
Ten PCI Express 2.0 slots that accommodate low-profile PCIe cards. All slots
support x8 PCIe cards. Two slots are also capable of supporting x16 PCIe cards.
• Slots 4 and 5: x4 electrical interface
• Slots 0, 1, 2, 7, 8, and 9: x8 electrical interface
• Slots 3 and 6: x8 electrical interface (x16 connector)
One specialized slot dedicated for use with the SPARC T3-2 Server 10 Gb Network
Module card. The server does not support populating this slot with standard PCIe
cards.
Four 10/100/1000 RJ-45 GbE ports on rear panel.
The service processor supports the following features:
• Integrated BMC, which supports the industry-standard IPMI feature set.
• Supports remote KVMS, DVD, and floppy over IP.
• Includes a serial port.
• Supports Ethernet access to SP through a dedicated 10/100BaseT management
port and optionally through one of the host GbE ports (using Oracle ILOM
sideband management).
Two hot-swappable power supplies, each with autoranging, light load efficiency
mode and redundant oversubscription.
Six hot-swappable, redundant fans at chassis front (top-loading); redundant fans in
each power supply.
Oracle ILOM.
