Electrical Specifications

Description
Maximum Depth (from bezel front to rear protrusions)
Weight (fully configured without PCIe cards)
Minimum service clearance (front)
Minimum service clearance (rear)
Minimum airflow clearance (front)
Minimum airflow clearance (rear)
†
Weight specifications vary based on the model and internal options.
Related Information
"Electrical Specifications" on page 18
■
"Input Power Information" on page 19
■
"Overcurrent Protection Requirements" on page 20
■
"DC Power Source, Power Connection, and Grounding Requirements" on page 21
■
"Environmental Requirements" on page 22
■
"Acoustic Noise Emissions" on page 23
■
"Airflow Precautions" on page 23
■

Electrical Specifications

The values in this table are for the power supplies. Use the online power calculator to determine
the power consumption of a server with your configuration:
powercalculators.
Parameter
Voltage (nominal)
Input current (maximum)
Frequency (nominal)
DC input treatment
18 Netra Server X5-2 Installation Guide • June 2016
†
AC
100 VAC (Japan only)
110 to 127 (90 to 132 range)
200 to 240 VAC (180 to 264 VAC range)
10A @ 100 VAC
9A @ 110-127 VAC
5.5A @ 200-240 VAC
50/60 Hz (47 to 63 Hz range)
N/A
U.S.
25.2 in.
45 lb
36 in.
36 in.
2 in.
3 in.
http://www.oracle.com/goto/
DC
−48 or −60 VDC (−40 to −72 VDC range)
21.5A @ −48 VDC
17A @ −60VDC
N/A
Isolated DC Return (DC-I)
Metric
640 mm
20.45kg
914.4 mm
914.4 mm
50.8 mm
76.2 mm
