Electrical Specifications

Description
Maximum Width (from bezel front to rear protrusions)
Depth (chassis)
Maximum Depth (from bezel front to rear protrusions)
Weight (fully configured without PCIe cards)
Minimum service clearance (front)
Minimum service clearance (rear)
Minimum airflow clearance (front)
Minimum airflow clearance (rear)
†
Weight specifications vary based on internal options.
Related Information
"Electrical Specifications" on page 18
■
"Input Power Information" on page 19
■
"DC Power Source, Power Connection, and Grounding Requirements" on page 21
■
"Overcurrent Protection Requirements" on page 20
■
"Environmental Requirements" on page 22
■
"Acoustic Noise Emissions" on page 23
■
"Airflow Precautions" on page 24
■

Electrical Specifications

The values in this table are for the power supplies. Use the online power calculator to determine
the power consumption of a server with your configuration:
powercalculators.
Parameter
Voltage (nominal)
Input current (maximum)
Frequency (nominal)
18 Netra SPARC S7-2 Server Installation Guide • January 2017
†
AC
100-127 VAC (800W max out)
200 to 240 VAC (1200W max out)
10A (100-127 VAC)
7A (200-240 VAC)
50/60 Hz
U.S. Metric
17.52 in. 445 mm
23.9 in. 608 mm
25.2 in. 640 mm
47.3 lb 21.5 kg
36 in. 914.4 mm
36 in. 914.4 mm
2 in. 50.8 mm
3 in. 76.2 mm
http://www.oracle.com/goto/
DC
-48/-60 VDC (1200W max out)
40-47 VDC (900W max out)
36A max @ -48 VDC bus
28A max @ -60 VDC bus
0 Hz
