▼ Install the CMA

The cable management arm is an optional assembly that you can use to route the
server cables in the rack.
1. Unpack the CMA parts.
2. Take the CMA to the back of the equipment rack and ensure that you have
adequate room to work around the back of the server.
Note – References to "left" or "right" in this procedure assume that you are facing
the back of the equipment rack.
3. Remove tape to separate the parts of the CMA.
