Electrical Specifications

Related Information
"Server Overview" on page 10
■
"Handling Precautions" on page 23
■
"Installing the Server" on page 25
■
"Electrical Specifications" on page 16
■
"Environmental Specifications" on page 17
■
"Airflow Precautions" on page 18
■
Electrical Specifications
Description
Voltage
Frequency
Maximum operating input current at 200 VAC (per
†
cord)
Maximum operating input current at 200 VAC (all
inputs)
Maximum operating input power at 200 VAC
Maximum standby power
Idle input power (maximum configuration)
Idle input power (minimum configuration)
Peak AC power (maximum configuration)
Peak AC power (minimum configuration)
Maximum heat dissipation
†
The maximum operating input current values are based on P / (V *0.90), where P = max. operating input power, V= input voltage. Example:
620W / (120 * 0.90) = 6.89A You can use this equation to calculate your maximum operating current at your input voltage.
‡
Maximum server configuration specification under nominal temperature and voltage conditions (one 4.133-GHz T7 processor with sixteen
32GB DDR4 DIMMs, 4 HDDs, 4 NVMe SFFs, and 6 I/O cards).
*
Minimum server configuration specification under nominal temperature and voltage conditions (one 4.133-GHz T7 processor with eight
16-GB DDR4 DIMMs, no HDD, and no I/O cards).
For information on power specifications, use the power calculator at:
http://www.oracle.com/us/products/servers-storage/sun-power-calculators
16 SPARC T7-1 Server Installation Guide • October 2015
†
Value
200 to 240 VAC
50 to 60 Hz
5.7 A
7.0A
1370W
20W
‡
658W
*
398W
‡
1306W
*
634W
4456 BTU/hr
4702 KJ/hr
Notes
Actual amperage draw may
exceed rating by no more than
10%.
Conforms to SpecJBB.
Conforms to SpecJBB.
