Signal
GND
SDA
SCL
ModSelL
ResetL
LPMode
ModPrsL
IntL
Related Information
"Rear Panel Connectors and Ports" on page 37
■
"Connect the Network Module Cables" on page 42
■
70
SPARC T3-2 Server Installation Guide • March 2012
Description
Ground for both signal and power return
2
I
C interface data
2
I
C interface clock
Module select on low - Enables reception of I
Reset on low
Low power mode
Module presence on low - Identifies existence of QSFP connector.
Interrupt on low - Enables fault indication.
2
C commands.
