▼ Connect the Ethernet Network Cables

The server has four Gigabit Ethernet network connectors, marked NET0, NET1,
NET2, and NET3. Use these ports to connect the server to the network.
Note – The ILOM sideband management feature enables you to access the SP using
one of these Ethernet ports. Refer to the SPARC T3 Series Servers Administration Guide
for instructions.
1. Connect a Category 5 (or better) cable from your network switch or hub to
Ethernet Port 0 (NET0) on the rear of the chassis.
2. Connect Category 5 (or better) cables from your network switch or hub to the
remaining Ethernet ports (NET1, NET2, NET3), as needed.
Related Information
SPARC T3 Series Server Administration Guide
■
"Powering On the Server for the First Time" on page 49
■
"Gigabit Ethernet Ports" on page 65
■
Connecting the Server Cables 41
