Note – Cable hooks and loop straps are preinstalled on the CMA. Perform the
procedure in this step if you need to reinstall cable hooks and straps on the CMA.
For best results, place three cable straps, evenly spaced, on the rear-facing side of
the CMA and three cable straps on the side of the CMA nearest the server.
FIGURE:
Figure Legend
1
2
Related Information
"Verify Operation of Slide Rails and CMA" on page 33
■
"Secure Cables to CMA" on page 47
■
32
SPARC T3-2 Server Installation Guide • March 2012
Installing CMA Cable Straps
CMA cable strap
CMA arm
