SAS Connector Pinouts (Continued)
TABLE:
Power Segment
Related Information
SPARC T3-2 Server Service Manual
■
68 SPARC T3-2 Server Installation Guide • March 2012
P1 3.3V
P2 3.3V
P3 3.3V
P4 Gnd
P5 Gnd
P6 Gnd
P7 5.0V
P8 5.0V
P9 5.0V
P10 Gnd
P11 Reserved
P12 Gnd
P13 12.0V
P14 12.0V
P15 12.0V
Not Supported
Not Supported
Not Supported
First mate
Second mate
Second mate
Pre-charge, second mate
Second mate
Should be grounded
First mate
Pre-charge, second mate
