5. Select Cycle Pick/Place by pressing
The system displays the following screen:
Set Source
↑ Increase
↓ Decrease
6. Select the element index of the cartridge slot from which you want the
CHM to pick and place the cartridge (shown in the upper right corner) by
↑ ↓
pressing or , then Enter.
The system displays this screen:
Set Cycles
↑ Increase
↓ Decrease
7. Select the number of cycles (in increments of ten) you want the Cycle
Pick/Place to run by pressing
The test picks a cartridge from the element you specify and places it back in
the same element.
To abort this diagnostic, press Escape and then Enter.

To run the Cycle Gripper test

The Cycle Gripper test opens and closes the gripper the number of times you
specify. For best results, move the CHM to the home position by first running
Home CHM (as described in the following procedure) so you can see the
movement of the gripper through the library window.
1. Disable security (the display panel reads Set Security On when security is
disabled).
If the display panel reads Set Security Off, security is turned on. See "To
enable or disable security" on page 2-22.
2. Put the tape library into LCD Interface mode:
a. Press Escape until the primary menu is displayed.
b. Select the Interface Menu by pressing
c. Select the Control Mode Menu by pressing
d. Select LCD Interface mode by pressing
Troubleshooting
↓ ↑
or , then Enter.
0
10
↑ ↓
or , then Enter.
↓ ↑
or , then Enter.
↓ ↑
or
↓ ↑
or , then Enter.
2
, then Enter.
2-37
