6. Disconnect the display panel cable from the J10 connector (outside
connector) on the SMC controller card.
See Figure 6-15.

Figure 6-15 Disconnecting or Connecting the Display Panel Cable

Removing and Installing Replacement Parts
Display panel
cable
J10 connector
SMC controller card
6
6-21
