Table D-2 Hardware Error Sense Key (4h) ASC and ASCQ Values

ASC ASCQ
Byte 12 Byte 13
15h 80h
15h 81h
15h 83h
15h 84h
15h 85h
3Bh 81h
3Fh 80h
3Fh 81h
3Fh 82h
3Fh 83h
3Fh 84h
3Fh 85h
3Fh 86h
40h 80h
40h 81h
40h 82h
40h 83h
40h 85h
40h 86h
40h 87h
40h 88h
Error Codes
Display Description
Panel
Number
10 The CHM dropped a cartridge.
14 The CHM could not successfully pick a cartridge.
13 The CHM could not successfully place a cartridge.
25 The CHM stalled while trying to pick a cartridge from the
tape drive.
26 The gripper could not open.
71 Firmware error.
N/A The tape library is unable to erase the flash EEPROM 1.
N/A The tape library is unable to erase the flash EEPROM 2.
N/A The tape library is unable to write zeros to the flash
EEPROM 1.
N/A The tape library is unable to write zeros to the flash
EEPROM 2.
N/A The tape library is unable to program the flash EEPROM 1.
N/A The tape library is unable to program the flash EEPROM 2.
N/A The flash EEPROM checksum was bad.
01 Internal clock failure.
02 Internal RAM failure.
03 Internal ROM failure.
04 +24-volt power supply failure.
06 +12-volt power supply failure.
07 -12-volt power supply failure.
08 Digital/analog converter failure.
72 The front door is open or the door solenoid is
malfunctioning.
D
D-3
