Sun StorEdge
S1 Array
™
Installation and Maintenance
Manual
Sun Microsystems, Inc.
4150 Network Circle
Santa Clara, CA 95054 U.S.A.
650-960-1300
Part No. 816-0080-12
April 2003, Revision A
Submit comments about this document at: http://www.sun.com/hwdocs/feedback
