What's this?
• The user should be able to contact service personnel like Fire
Brigade, Ambulance, etc. from ISDN and GSM network, when he is
facing some adverse situation and needs some help. This is known
as 'Emergency Number Dialing'.
• SIMADO GBR42 supports this feature for BRI and Mobile port. For
ISDN network fixed emergency numbers can be dialed from the
gateway, from any TE port. But for GSM network, it may happen
that you need to call emergency number even when you have not
inserted the SIM card and the module is not registered with the
network. This is called 'False' status of the GSM port. Normally SIM
card is inserted and the module is registered with the network. This
is called 'True' status of the GSM port. SIMADO GBR42 supports
the emergency dialing feature for both status of GSM port, just like
a mobile handset.
• If required, user can program the number string using following
Codes for the Special digits:
Special Digit
Flash
Pause
A
B
C
D
+
#
Warning!
• This feature will not work, if DC power to 12VDC jack fails.
How it works?
• The system supports 4 programmable numbers and routing group,
which will be used as emergency numbers for dialing. Each
number is of 4 digits maximum.
• The dialed number is compared with numbers programmed in the
emergency number table. If it matches by prefect fit logic then the
number is dialed out from the port, selected by routing logic using
78

Emergency Number Dialing

Code
#2
#3
#4
#5
#6
#7
#8
##
