Overlap Receiving Timer is from 001 to 255 seconds.
By default, Overlap Receiving Timer is 15 seconds.
Step 9
Use following command to program the idle code for the TE port:
410-TE Port-Idle Code-#*
Where,
TE is from 1 to 2.
Idle Code is from 000 to 255 (Corresponding to 8 bits).
The binary equivalent of the programmed value (000 to 255) is sent
on the channel to signify that the channel is idle (or unused). This
setting depends on the network. Most commonly applicable values
are 7F and FF (Binary equivalent is 0111 1111 and 1111 1111, decimal
equivalent is 127 and 255).
By default Idle Code is 127 (7F).
Step 10
Use following command to assign the 'Type of Network' with which,
the TE port is interfaced:
411-TE Port-Code-#*
Where,
TE Port is from 1 to 2.
Code Meaning
1
Public ISDN
2
Private ISDN
By default, Type of Network is '1' for TE Port.
Note:
• The ISDN line subscribed from the telephone exchange is
connected on the TE port.
Step 11
Use following command to program the DDI Pilot Number for the TE
port:
412-TE Port-DDI Pilot Number-#*
Where,
TE Port is from 1 to 2.
DDI Pilot Number is number string of 16 digits maximum, with digits
0-9.
SIMADO GBR42 V1 System Manual
Matrix
153
