By default, Pilot Number for the TE port is Blank.
Step 12
Use following command to program the Start DDI Number for the TE
port:
413-TE Port-DDI Start Number-#*
Where,
TE Port is from 1 to 2.
DDI Start Number is a number string of 16 digits maximum, with digits
0-9.
By default, Start DDI Number for the TE port is Blank.
Step 13
Use following command to program the Total DDI Number for the TE
port:
414-TE Port-Total DDI Number-#*
Where,
TE Port is from 1 to 2.
Total DDI Number is from 0001 to 9999, with 4-digits Maximum.
By default, Total DDI Number for the TE Port is 0100.
Step 14
Use following command to program the DDI Number of digits for the
TE port:
415-TE Port-DDI Number of Digits-#*
Where,
Total DDI Number of digits is from 0 to 4.
By default, DDI Number of Digits for the TE Port is 2.
Step 15
• This gives option for allowing or denying the Incoming calls on this
port.
• If this option is set to "Deny", the port can not be used as source
port as all the call originating on this port will get rejected.
• If this option is set to "Allow", the port can be used as source port.
All the calls originating on this port will get routed based on the
programming.
• If this port is 'Destination Port' this command is not applicable.
