RJ-45 connector wiring:
4
3
2
1
Connector wiring for TE interface
4
3
2
1
Connector wiring for NT interface
Connection of the ISDN GSM Gateway to a PC via RS232C Cable
SIMADO GBR42 V1 System Manual
1 not connected
5
2 not connected
3 Tx
6
4 Rx
5 Rx
7
6 Tx
7 not connected
8
8 not connected
5 1 not connected
2 not connected
3 Rx
6
4 Tx
5 Tx
7
6 Rx
7 not connected
8
8 not connected
5
4 3 2 1
6 7 8 9
1 DCD
2 RxD
3 TxD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
