Communication Port - Matrix Telecom SIMADO GBR42 System Manual

What's this?
• The SIMADO GBR42 supports a communication port which is used
for following purpose:
• To send the Call Detail Recording (CDR) report to the computer.
• For programming through Jeeves.
• To send system event log to the PC.
• Based on application, a process is assigned to the COM port.
How to use it?
• Connect the communication port of the gateway with the
communication port of the computer using a crossed
communication cable. Matrix provides a crossed communication
cable with 9-pin D-type female connector on both the sides.
The Jeeves software for the gateway can be installed on any standard
computer with Window and NT operating system.
COM 1
SIMADO
GBR42
Following attributes are used for the system and are not
programmable:
Baud Rate
Stop Bit
Parity
Data Bits
Flow Control
SIMADO GBR42 V1 System Manual

Communication Port

RS232C Cable
(Crossed)
19200bps
1
Mark
8
None
Matrix
COM 1
Computer
