What's this?
• Various features and facilities provided by the gateway, use date
and time parameters. These features are:
• Defining four timezones in the table.
• Routing type for the NT, TE and Mobile port for timezone.
• Routing group for the NT, TE and Mobile port for timezone.
• Such facilities work properly only if the system is set with correct
date and time values.
• For this SIMADO GBR42 is designed with built in Real Time Clock
(RTC) circuit. This circuit is to be set once with current date and
time values. It then updates itself regularly to keep track of the
parameters.
However, please note that the RTC circuit can drift over a long
period. Hence it is recommended to check and reset RTC values
at least once every month to correct this drift. Please note that
the system RTC takes care of the leap year.
How to program?
Step 1: To program the system date using command 101.
Step 2: To program the Day of the week using command 102.
Step 3: To program the system time using command 103.
Step 1
Use following command to program the current date:
101-DD-MM-YYYY-#*
Where,
DD is from 01 to 31 (leading zero is must in case of single digit).
MM is from 01 to 12 (leading zero is must in case of single digit).
YYYY is from 0000 to 9999.
By default, Date is 01-01-2006.
Step 2
Use following command to program the day of the week:
102-Day-#*
Where,
Day is a single digit ranging from 1 to 7.
116
Real Time Clock (RTC)
SIMADO GBR42 V1 System Manual
