Following table gives the pin out details of the COM port:
Pin No. Signal Name
1 Data Carrier Detect (DTD)
2 Receive Data (RXD)
3 Transmit Data (TXD)
4 Data Terminal Ready (DTR)
5 Ground (GND)
6 Data Set Ready (DSR)
7 Request to Send (RTS)
8 Clear to Send (CTS)
9 Ring Indidcator (IR)
How to program?
Use following command to enable/disable event logging process:
214-Code-#*
Where,
Code Me a ning
0 Disable
1 Enable
By default, Event Logging Process is 0.
Important Points:
• Only one process can be started from COM port: Jeeves, CDR
report or Debugging.
• From Jeeves, report = start/stop or debug = start/stop can be
operated.
