FINAL DRIVE
12. Rotate bearing by hand and check for smooth
rotation. Visually inspect bearing for moisture, dirt, or
corrosion.
IMPORTANT
Due to extremely close tolerances and minimal wear,
the bearings must be inspected visually, and by feel.
While rotating bearings by hand, inspect for rough
spots, discoloration, or corrosion. The bearings should
turn smoothly and quietly, with no detectable up and
down movement and minimal movement sideways
between inner and outer race.
13. Replace hub assembly if moisture, dirt, corrosion, or
roughness is evident. The bearing should also be
inspected for any scratches, wear, or damage.
Replace hub assembly if it is damaged.
8.4
FRONT BEARING CARRIER
INSTALLATION
1. Install bearing carrier into steering knuckle. Torque
fasteners to specification.
TORQUE
Hub Assembly Mounting Fasteners:
81 ft-lbs (110 Nm)
2. Install half shaft axle through the backside of the
bearing carrier.
3. Install the upper and lower ball joint ends into the
front bearing carrier.
4. Install upper ball joint pinch bolt and lower ball joint
nut. Torque to specification.
TORQUE
Upper Ball Joint Pinch Bolt:
52 ft-lbs (70 Nm) - Torque bolt side
TORQUE
Lower Ball Joint Nut:
44 ft-lbs (60 Nm) + 90° (Single Use)
