4. install a new retaining ring
5. Measure the installed end gap of the retaining ring to
ensure it is fully seated and within specification.
MEASUREMENT
Retaining Ring Installed End Gap:
No greater than 5 mm
6. If the installed end gap of the retaining ring exceeds 5
mm, remove retaining ring, inspect and clean groove
as necessary. Install a NEW retaining ring and repeat
measurement.
7. Repeat the ball joint service procedure for any
additional control arm ball joint replacements.
8. Refer to upper/lower control arm replacement for
installation procedure and applicable torque
specifications.
